model:JF

server cabinet

Description :
K/D Server Rack
Mat. : Aluminum
Cabinet Rack series:19" Cabinet Rack, Server Rack, Rack Cabinets, Rack Mount Instrument. more.....

SPECIFICATIONS
Key Specifications/Special Features:

  • Specifications
    ◦ Standard 19-inch Cabinet rack.
    ◦ Must follow ANSI/EIA RS-310-C, D, E, F criterions to manufacture.
    ◦ UL and CE-approved, and MIL-STD-167 tested.
  • Surface and structure
    ◦ Surface:
          ▪ External width: 600mm.
          ▪ Height : 15~42U.
          ▪ Depth: 900mm.
          ▪ 1U for 44.45mm.
    ◦ Structure:
            ▪ Must follow ANSI/EIARS-310-C, D, E, F criterions to manufacture.
            ▪ UL and CE-approved.
            ▪ and MIL-STD-167 tested.
            ▪ Main aluminum vertical rails uses squeeze aluminum pillars; an arc type appearance; material:
              AL6063T5.
            ▪ Flexible aluminum vertical rails can be set at the Cabinet rack's front and back to meet the
              terminal wire's needs (it should have at least three grooves).
            ▪ User can add the cable fixtures accordingly.
            ▪ Cabinet Rack's external depth is 900mm, and its internal.
            ▪ depth must reach 750mm.
            ▪ 6-way universal socket strips (1 set) with switch.
            ▪ 50 sets of catch nuts and panel screws are the standard outfit
              (you may add copper rails for your rack).
            ▪ Flexible aluminum vertical rail's apertures must be able to install the M5 or M6.
            ▪ catch nuts, and aperture-to-aperture's distance must follow.
            ▪ EIA-Rs-310C criterions (size cannot be smaller than 9.2 x 9.2mm).
            ▪ Flexible aluminum vertical rail's.
            ▪ thickness must higher than 2mm.
            ▪ Removable aluminum vertical rails can be adjusted forwards or backwards.
            ▪ Powder coated to protect against rust, oxidization, scratches, lacquer peeling, strong acid and
              alkali erosion.
            ▪ Cabinet Rack's side panel can be easily assembled and disassembled from the outside
              without
    using any tools.
            ▪ 2 sets of UL and CE-approved cooling fans as standard outfit.
            ▪ Fan size: 120 x 25mm (increasing the number of fans is optional).
            ▪ Screw-less appearance for a smooth and clean look.


Specification:

Order Code Capacity(U) Width(mm) Depth(mm)
JF-42-900 42U 600 900
JF-42-1000 600 1000
JF-42-1100 600 1100
JF-41-615 41U 600 615
JF-41-750 600 750
JF-41-900 600 900
JF-41-1000 600 1000
JF-41-1100 600 1100
JF-35-615 35U 600 615
JF-35-750 600 750
JF-35-900 600 900
JF-30-615 30U 600 615
JF-30-750 600 750
JF-30-900 600 900
JF-25-615 25U 600 615
JF-25-750 600 750
JF-25-900 600 900
JF-20-615 20U 600 615
JF-20-750 600 750
JF-20-900 600 900
JF-15-615 15U 600 615
JF-15-750 600 750
JF-15-900 600 900


Images:
